AutoIQ : Used Car Pricing System
Table of Contents
- Problem
- Solution
- Workflow
- Impact
- Dataset
- Setup
- Testing
- Dockerization
- Application
- Model Training & Evaluation
- Challenges & Solutions
- Folder Structure
- License
Problem
- In the used-car market, buyers and sellers often struggle to determine a fair price for a vehicle.
- Incorrect pricing leads to revenue loss when undervalued and slow sales when overpriced.
- The goal is to provide accurate and transparent pricing by analyzing real-world market listings.
Solution
- Built and deployed an ML pipeline predicting used-car prices from 2,800+ real Cars24 listings.
- Benchmarked 6 models, then selected tuned XGBoost for the best accuracy-to-complexity tradeoff.
- Deployed the model through a Dockerized FastAPI service with a live frontend for real-time predictions.
Workflow
Click Here to view Workflow Diagram
Impact
- Cut MAE by 31% (₹1,23,193 → ₹85,281) and improved R² from 0.77 to 0.88 over a Linear Regression baseline.
- Reduced MAE variability by 62% (std ₹6,435 → ₹2,426) over baseline for more consistent predictions.
- Validated on a held-out test set, achieving ₹87,723 MAE, 0.87 R², and ~14% MAPE on completely unseen data.
- Delivered data-backed price ranges instead of a single point estimate, enabling confident negotiation.
Dataset
- To train the model, I collected real-world used car listings data directly from the Cars24 website.
- Since Cars24 uses dynamically loaded content, a static scraper would not capture all the data.
- Instead, I implemented an automated Selenium + BeautifulSoup Python Script.
Web Scraping Script (scrape_car_listing)
Click Here to view more Details
**Input :** URL of a Cars24 listing page to scrape. #### 1. Launch Chrome Automatically - Script uses `ChromeDriverManager` to install and manage the drivers without manual setup. #### 2. Open Cars24 Website - Loads the given URL in a real browser session. #### 3. Simulate Scrolling - Scrolls down the page in increments, with short random pauses (2-4 seconds) between scrolls. - This ensures all dynamically loaded listings are fetched. #### 4. Check for End of Page - Stops scrolling when the bottom of the page is reached or no new content loads. #### 5. Capture Rendered HTML - Once fully loaded, it retrieves the complete DOM (including dynamically injected elements). #### 6. Parse HTML with BeautifulSoup - Returns a BeautifulSoup object containing the entire page's HTML for later parsing and data extraction. #### Note - At this stage, no data is extracted, the output is just the complete HTML source. - It will later be parsed by a separate script to extract features like price, model, year, transmission, etc.
Data Extraction Script (get_car_details)
Click Here to view more Details
**Input :** BeautifulSoup object (`soup`) containing the fully-rendered HTML of a Cars24 listing page. #### 1. Find Raw Model Name Texts - Looks for `` elements with class `sc-braxZu kjFjan`. - Extracts the text using `.text` into a list called `model_name`. - The code only keeps those car models that start with `2` and stores them in `clean_model_name`.
Click to view the HTML Element Snapshot
` elements with class `sc-braxZu kvfdZL` (each holds one specification value).
- These are appended to `specs` list.
```python
['69.95k km',
'Petrol',
'Manual',
'1st owner',
'DL-1C',
'70.72k km',
'Diesel',
'Manual',
'2nd owner',
'UP-14',
'15.96k km',
'CNG',
'Manual',
'1st owner',
'UP-16',...]
```
` tags with the class `sc-braxZu jjIUAi`.
- Checks if the text exactly matches "Engine capacity".
Click to view the HTML Element Snapshot
Click to view the HTML Element Snapshot
Click to view the HTML Element Snapshot
Click Here to view more Details
**Input :** List of URLs for individual car listings (`link` from the previous DataFrame).
#### 1. Iterate through each Car Listing URL
- Loops over the list of individual car listing page URL.
#### 2. Send an HTTP Request
- Uses the `requests` library to retrieve each page's HTML content.
- Adds a User-Agent header to simulate a real browser and reduce blocking risk.
- Applies a random delay of (4-8 seconds) between requests to avoid overloading the server.
#### 3. Parse the HTML Content
- Converts the response into a BeautifulSoup object using the `lxml` parser for fast, reliable parsing.
#### 4. Locate Engine Capacity Label
- Searches for all `Click to view the HTML Element Snapshot
Click Here to view Example Function
```python
# Parsing HTML Content of Hyderabad City from Cars24 Website
soup = scrape_car_listing('https://www.cars24.com/buy-used-cars-hyderabad/')
# Extracting Car Details of Hyderabad City
hyderabad = get_car_details(soup)
```
```python
# Parsing HTML Content of Bangalore City from Cars24 Website
soup = scrape_car_listing('https://www.cars24.com/buy-used-cars-bangalore/')
# Extracting Car Details of Bangalore City
bangalore = get_car_details(soup)
```
```python
# Parsing HTML Content of Mumbai City from Cars24 Website
soup = scrape_car_listing('https://www.cars24.com/buy-used-cars-mumbai/')
# Extracting Car Details of Mumbai City
mumbai = get_car_details(soup)
```
```python
# Parsing HTML Content of Delhi City from Cars24 Website
soup = scrape_car_listing('https://www.cars24.com/buy-used-cars-delhi-ncr/')
# Extracting Car Details of Delhi City
delhi = get_car_details(soup)
```
```python
# Concatenating Car Details of Different Cities into Single DataFrame
df = pd.concat([hyderabad, bangalore, mumbai, delhi], ignore_index=True)
df.head()
```
```python
# Extracting engine capacity of each car using its car listing link from Cars24 Website
engine_capacity = get_engine_capacity(df['link'])
# Adding "engine_capacity" column in the DataFrame
df['engine_capacity'] = engine_capacity
# Final DataFrame after Web Scraping
df.head()
```
Click Here to view more Details
The final dataset consists of 2,800+ unique car listings, with each record containing :
| Column | Description |
|:---|:---|
| `model_name` | Model name of car (2014 Hyundai Grand i10, etc.) |
| `fuel_type` | Fuel type (Petrol, Diesel, CNG, Electric) |
| `transmission` | Transmission type (Automatic or Manual) |
| `owner` | Previous owners count (1st owner, 2nd owner, 3rd owner, etc.) |
| `engine_capacity` | Engine size (in cc) |
| `km_driven` | Total distance traveled (in km) |
| `price` | Selling price (target variable) |
## Setup
Follow these steps carefully to setup and run the project on your local machine :
### 1. Clone the Repository
First, you need to clone the project from GitHub to your local system.
```bash
git clone https://github.com/themrityunjaypathak/AutoIQ.git
```
### 2. Build the Docker Image
Docker allows you to package the application with all its dependencies.
```bash
docker build -t your_image_name .
```
> [!TIP]
>
> Make sure Docker is installed and running on your machine before executing this command.
### 3. Setup Environment Variables
This project uses a `.env` file to store configuration settings like model paths, allowed origins, etc.
#### `.env` file
- Stores environment variables in plain text.
```bash
# .env
ENV=dev_or_prod
MODEL_FREQ_PATH=path/to/model_freq.pkl
PIPE_PATH=path/to/pipe.pkl
LOWER_PIPE_PATH=path/to/lower_pipe.pkl
UPPER_PIPE_PATH=path/to/upper_pipe.pkl
ALLOWED_ORIGINS=comma_separated_list_of_allowed_origins
```
> [!IMPORTANT]
> Never commit `.env` to GitHub / Docker.
>
> Add `.env` to `.gitignore` and `.dockerignore` to keep it private.
### 4. Run the Docker Container
Start the application using Docker. This will run the FastAPI server and handle all the dependencies automatically.
```bash
docker run --env-file .env -p 8000:8000 --name your_container_name your_image_name
```
> [!NOTE]
> `api.main` : Refers to the main.py file inside the api folder.
>
> `app` : The FastAPI instance defined in your code.
### 5. Access the FastAPI Server
Once the container is running, open your browser and navigate to :
```bash
http://127.0.0.1:8000/docs
```
This opens the Swagger UI for testing the API endpoints.
> [!IMPORTANT]
>
> If running the API locally :
>
> ```bash
> uvicorn api.main:app --reload --host 127.0.0.1 --port 8000
> ```
> Use the same host (`127.0.0.1`/`localhost`) for both the frontend and `ALLOWED_ORIGINS` in `.env`.
>
> A mismatch makes browsers treat them as different origins and CORS will fail.
Access the live API [here](https://autoiq.onrender.com/docs) or Click on the Image below.
### 6. Stop the Docker Container
When you're done using the application, stop the running container.
```bash
docker stop your_container_name
```
## Testing
Once the FastAPI server is running, you can test the API endpoints in Postman or any similar software.
### 1. Launch Postman and Create a New HTTP Request
- Launch the Postman application on your computer.
- Click on the "New" button, then select "HTTP" requests.
### 2. Using GET and POST Methods in Postman
Click Here for details about GET Method
### GET Method
- Retrieve information from the server without modifying any data.
### Steps
- Open Postman and create a new request.
- Set the HTTP method to "GET" from the dropdown menu.
- Enter the endpoint URL you want to query.
```
http://127.0.0.1:8000
```
- Click the "Send" button to submit the request.
### Expected Response
- **Status Code :** It indicates that the request was successful and the server responded with the requested data.
```
200 OK
```
- **Response Body (JSON) :** This confirms that the API is running and returns the result of your API call.
```json
{
"message":"Pipeline is live"
}
```
Click Here for details about POST Method
### POST Method
- Send data to a server to create/update a resource.
### Steps
- Open Postman and create a new request.
- Set the HTTP method to "POST" from the dropdown menu.
- Enter the endpoint URL you want to query.
```
http://127.0.0.1:8000/predict
```
- Navigate to the "Headers" tab and add the following : Key as `Content-Type`, Value as `application/json`
- Go to the "Body" tab, Select "raw", then choose "JSON" from the format dropdown menu.
- Enter the request payload in JSON format.
```json
{
"brand": "MG",
"model": "HECTOR",
"km_driven": 80000,
"engine_capacity": 1498,
"fuel_type": "Petrol",
"transmission": "Manual",
"year": 2022,
"owner": "1st owner"
}
```
- Click the "Send" button to submit the request.
### Expected Response
- **Status Code :** It indicates that the server successfully processed the request and generated a prediction.
```
200 OK
```
- **Response Body (JSON) :** This confirms that the API is running and returns the result of your API call.
```json
{
"output": "₹7,81,412 to ₹12,66,018"
}
```
## Dockerization
Follow these steps carefully to containerize your project with Docker :
### 1. Install Docker
- Before starting, make sure Docker is installed on your system.
- Visit [Docker](https://www.docker.com/) ➜ Click on Download Docker Desktop ➜ Choose Windows / Mac / Linux.
### 2. Verify the Installation
- Open Docker Desktop ➜ Make sure Docker Engine is Running.
### 3. Create the Dockerfile
- Create a `Dockerfile` and place it in the root folder of your Repository.
### 4. Create the `.dockerignore` File
- This file tells Docker which files and folders to exclude from the image.
- This keeps the image small and prevents unnecessary files from being copied.
### 5. Build the Docker Image
- A Docker image is essentially a read-only template that contains everything needed to run an application.
- You can think of a Docker image as a blueprint or snapshot of an environment. It doesn't run anything.
```bash
docker build -t your_image_name .
```
### 6. Create the Docker Container
- When you run a Docker image, it becomes a Docker container.
- It is a live instance of that image, running your application in an isolated environment.
```bash
docker run --env-file .env -p 8000:8000 your_image_name
```
After the container starts, you can access your API.
```bash
http://127.0.0.1:8000
```
### 7. Push to Docker Hub
- Once your Docker image is ready, you can push it to Docker Hub.
- It allows anyone to pull and run it without building it themselves.
Click Here for steps to Push to Docker Hub
#### Login to Docker Hub
- Prompts you to enter your Docker Hub username and password.
- This authenticates your local Docker client with your Docker Hub account.
```bash
docker login
```
#### Tag the Docker Image
- Tagging prepares the image for upload to Docker Hub.
```bash
docker tag your_image_name your_dockerhub_username/your_image_name:latest
```
#### Push the Image to Docker Hub
- Uploads your image to your Docker Hub Repository.
- Once pushed, your image is publicly available.
- Anyone can now pull and run the image without building it locally.
```bash
docker push your_dockerhub_username/your_image_name:latest
```
### 8. Pull and Run Anywhere
- Once pushed, anyone can pull your image from Docker Hub and run it.
- This ensures that the application behaves the same way across all systems.
```bash
docker pull your_dockerhub_username/your_image_name:latest
```
- After pulling the Docker image, you can run it to create a Docker container from it.
```bash
docker run --env-file .env -p 8000:8000 your_dockerhub_username/your_image_name:latest
```
### 9. Verify the Container is Running
- Lists all the running containers with `container_id`.
```bash
docker ps
```
### 10. Stop the Container
- Stops the running container safely.
- `container_id` can be obtained from `docker ps` output.
```bash
docker stop container_id
```
## Application
The frontend application files are in the `frontend/` folder :
- `index.html` : This file defines the structure and layout of the web page.
- `style.css` : This file handles the visual appearance of the web page.
- `script.js` : This file communicates between the web page and the REST API.
> [!IMPORTANT]
> If you clone this repo and want `script.js` to hit your local API instead of the live one, update the fetch URL.
>
> Change from :
> ```js
> const fetchPromise = fetch("https://autoiq.onrender.com/predict", {
> method: "POST",
> headers: { "Content-Type": "application/json" },
> body: JSON.stringify(data),
> });
> ```
>
> To :
> ```js
> const fetchPromise = fetch("http://127.0.0.1:8000/predict", {
> method: "POST",
> headers: { "Content-Type": "application/json" },
> body: JSON.stringify(data),
> });
> ```
> [!NOTE]
>
> The API for this project is deployed using the free tier on Render.
>
> As a result, it may go to sleep after periods of inactivity.
>
> Please start the API first by visiting the API URL. Then, navigate to the website to make predictions.
>
> If the API was inactive, the first prediction may take a few seconds while the server spins back up.
Access the live website [here](https://autoiqlabs.vercel.app) or Click on the Image below.
## Model Training & Evaluation
### 1. Load the Data
Click Here to view Code Snippet
```python
# Importing load_parquet function from read_data module
from read_data import load_parquet
cars = load_parquet('clean_data', 'clean_data_after_eda.parquet')
cars.head()
```
### 2. Split the Data
Click Here to view Code Snippet
```python
# Creating Features and Target Variable
X = cars.drop('price', axis=1)
y = cars['price']
```
```python
# Splitting Data into Training and Testing Set
X_train, X_test, y_train, y_test = train_test_split(X, y, test_size=0.25, random_state=42)
```
### 3. Build Preprocessing Pipeline
Click Here to view Code Snippet
```python
# Pipeline for Nominal Column
nominal_cols = ['fuel_type','transmission','brand']
nominal_trf = Pipeline(steps=[
('ohe', OneHotEncoder(sparse_output=False, handle_unknown='ignore'))
])
```
```python
# Pipeline for Ordinal Column
ordinal_cols = ['owner']
ordinal_categories = [['Others','3rd owner','2nd owner','1st owner']]
ordinal_trf = Pipeline(steps=[
('oe', OrdinalEncoder(categories=ordinal_categories))
])
```
```python
# Pipeline for Numerical Column
numerical_cols = ['km_driven','year','engine_capacity']
numerical_trf = Pipeline(steps=[
('scaler', RobustScaler())
])
```
```python
# Adding Everything into ColumnTransformer
ctf = ColumnTransformer(transformers=[
('nominal', nominal_trf, nominal_cols),
('ordinal', ordinal_trf, ordinal_cols),
('scaling', numerical_trf, numerical_cols)
], remainder='passthrough', n_jobs=-1)
```
### 4. Evaluate Multiple Models
Click Here to view Code Snippet
```python
# Models Dictionary
models = {
'LR' : LinearRegression(n_jobs=-1),
'KNN' : KNeighborsRegressor(n_jobs=-1),
'DT' : DecisionTreeRegressor(random_state=42),
'RF' : RandomForestRegressor(random_state=42, n_jobs=-1),
'GB' : GradientBoostingRegressor(random_state=42),
'XGB' : XGBRegressor(random_state=42, n_jobs=-1)
}
```
```python
# Computing Metrics through Cross-Validation
results = {}
for name, model in models.items():
pipe = Pipeline(steps=[
('preprocessor', ctf),
('model', model)
])
k = KFold(n_splits=5, shuffle=True, random_state=42)
cv_results = cross_validate(estimator=pipe, X=X_train, y=y_train, cv=k, scoring={'mae':'neg_mean_absolute_error','r2':'r2'}, n_jobs=-1, return_train_score=False)
results[name] = {'avg_error': -cv_results['test_mae'].mean(),'avg_score': cv_results['test_r2'].mean()}
print()
print(f'Model : {name}')
print('-'*40)
print(f'Average Error : {-cv_results['test_mae'].mean():.2f}')
print(f'Standard Deviation of Error : {cv_results['test_mae'].std():.2f}')
print(f'Average R2-Score : {cv_results['test_r2'].mean():.2f}')
print(f'Error Stability (CV of MAE) : {(cv_results['test_mae'].std() / -cv_results['test_mae'].mean()) * 100:.2f}%')
```
Click Here to view Analysis
```
Model : LR
----------------------------------------
Average Error : 123193.35
Standard Deviation of Error : 6435.48
Average R2-Score : 0.77
Error Stability (CV of MAE) : 5.22%
Model : KNN
----------------------------------------
Average Error : 115518.58
Standard Deviation of Error : 3843.92
Average R2-Score : 0.79
Error Stability (CV of MAE) : 3.33%
Model : DT
----------------------------------------
Average Error : 116187.61
Standard Deviation of Error : 4254.52
Average R2-Score : 0.76
Error Stability (CV of MAE) : 3.66%
Model : RF
----------------------------------------
Average Error : 90937.17
Standard Deviation of Error : 2666.87
Average R2-Score : 0.86
Error Stability (CV of MAE) : 2.93%
Model : GB
----------------------------------------
Average Error : 98130.73
Standard Deviation of Error : 3453.66
Average R2-Score : 0.85
Error Stability (CV of MAE) : 3.52%
Model : XGB
----------------------------------------
Average Error : 90899.92
Standard Deviation of Error : 1913.66
Average R2-Score : 0.86
Error Stability (CV of MAE) : 2.11%
```
### 5. Evaluate StackingRegressor Model
Click Here to view Code Snippet
```python
# Evaluating StackingRegressor (RF + XGB + GB -> ElasticNet meta-learner)
from sklearn.ensemble import StackingRegressor
from sklearn.linear_model import ElasticNet
stack_estimators = [
('rf', RandomForestRegressor(random_state=42, n_jobs=-1)),
('xgb', XGBRegressor(random_state=42, n_jobs=-1)),
('gb', GradientBoostingRegressor(random_state=42))
]
stack_model = StackingRegressor(
estimators=stack_estimators,
final_estimator=ElasticNet(random_state=42),
n_jobs=-1
)
stack_pipe = Pipeline(steps=[
('preprocessor', ctf),
('model', stack_model)
])
k = KFold(n_splits=5, shuffle=True, random_state=42)
stack_cv_results = cross_validate(estimator=stack_pipe, X=X_train, y=y_train, cv=k, scoring={'mae':'neg_mean_absolute_error','r2':'r2'}, n_jobs=-1, return_train_score=False)
stack_mae = -stack_cv_results['test_mae'].mean()
stack_std = stack_cv_results['test_mae'].std()
stack_r2 = stack_cv_results['test_r2'].mean()
print(f'Model : StackingRegressor')
print('-'*40)
print(f'Average Error : {stack_mae:.2f}')
print(f'Standard Deviation of Error : {stack_std:.2f}')
print(f'Average R2-Score : {stack_r2:.2f}')
print(f'Error Stability (CV of MAE) : {(stack_std / stack_mae) * 100:.2f}%')
print('')
```
Click Here to view Analysis
```
Model : StackingRegressor
----------------------------------------
Average Error : 87884.49
Standard Deviation of Error : 1488.70
Average R2-Score : 0.87
Error Stability (CV of MAE) : 1.69%
```
### 6. Choosing a Single Model
Click Here to view Code Snippet
```python
# Creating Object of the Model
xgb = XGBRegressor(random_state=42, n_jobs=-1)
# Final Pipeline with XGBRegressor
pipe = Pipeline(steps=[
('preprocessor', ctf),
('model', xgb)
])
```
```python
# Computing Metrics through Cross-Validation
cv_results = cross_validate(estimator=pipe, X=X_train, y=y_train, cv=k, scoring={'mae':'neg_mean_absolute_error','r2':'r2'}, n_jobs=-1)
print(f"Average Error : {-cv_results['test_mae'].mean():.2f}")
print(f"Standard Deviation of Error : {cv_results['test_mae'].std():.2f}")
print(f"Average R2-Score : {cv_results['test_r2'].mean():.2f}")
print(f"Error Stability (CV of MAE) : {(cv_results['test_mae'].std() / -cv_results['test_mae'].mean()) * 100:.2f}%")
```
Click Here to view Analysis
```
Average Error : 90899.92
Standard Deviation of Error : 1913.66
Average R2-Score : 0.86
Error Stability (CV of MAE) : 2.11%
```
- The graph shows model performance by average error (lower is better) and average R2 (higher is better).
- RandomForestRegressor and XGBRegressor are the top performers (\~₹90,900 MAE & R2 0.86).
- A StackingRegressor was also tried, improving MAE by only \~3% for 3x the model complexity and inference time.
```md
[StackingRegressor]
RF XGB GB
\ | /
\ | /
\ | /
▼ ▼ ▼
ElasticNet
[meta-learner]
│
▼
Final Prediction
```
- Not worth the trade-off for this project's scope, so **XGBRegressor** is used directly :
- It ties RF on error but has the lowest standard deviation of error (XGB's ₹1,913 vs RF's ₹2,667),
- It means more consistent predictions across folds.
- Being a single model, it's also simpler to tune, explain, and serve than a 3-model stack.
### 6. Performance Evaluation Graphs
#### Actual vs Predicted Plot
Click Here to view Analysis
| |
|
|---|---|
Click Here to view Analysis
| R2-Score Curve | Error Curve |
|---|---|
| |
|
### 7. Hyperparameter Tuning
Click Here to view Code Snippet
```python
# Parameter Distribution
param_dist = {
'model__n_estimators': [200, 300, 400],
'model__learning_rate': [0.03, 0.05, 0.1],
'model__max_depth': [2, 3, 4],
'model__subsample': [0.5, 0.75, 1.0],
'model__colsample_bytree': [0.5, 0.75, 1.0],
'model__min_child_weight': [1, 3, 5]
}
```
```python
# RandomizedSearchCV Object with Cross-Validation
rcv = RandomizedSearchCV(estimator=pipe, param_distributions=param_dist, cv=k, scoring='neg_mean_absolute_error', n_iter=30, n_jobs=-1, random_state=42)
```
```python
# Fitting the RandomizedSearchCV Object
rcv.fit(X_train, y_train)
```
```python
# Best Parameter
rcv.best_params_
```
```python
# Best Estimator
best_model = rcv.best_estimator_
```
```python
# Computing Metrics through Cross-Validation after Tuning
cv_results = cross_validate(estimator=best_model, X=X_train, y=y_train, cv=k, scoring={'mae':'neg_mean_absolute_error','r2':'r2'}, n_jobs=-1)
print(f"Average Error : {-cv_results['test_mae'].mean():.2f}")
print(f"Standard Deviation of Error : {cv_results['test_mae'].std():.2f}")
print(f"Average R2-Score : {cv_results['test_r2'].mean():.2f}")
print(f"Error Stability (CV of MAE) : {(cv_results['test_mae'].std() / -cv_results['test_mae'].mean()) * 100:.2f}%")
```
Click Here to view Analysis
```
Average Error : 85281.35
Standard Deviation of Error : 2426.39
Average R2-Score : 0.88
Error Stability (CV of MAE) : 2.85%
```
### 8. Performance Evaluation Comparison
#### Actual vs Predicted Plot
Click Here to view Analysis
| Before Tuning | After Tuning |
|---|---|
| |
|
Click Here to view Analysis
| R2-Score Curve (Before Tuning) | R2-Score Curve (After Tuning) |
|---|---|
| |
|
| Error Curve (Before Tuning) | Error Curve (After Tuning) |
|---|---|
|
|
|
### 9. Final Model Evaluation on Unseen Data
Click Here to view Code Snippet
```python
# Model Performance on Unseen Data
y_pred_test = best_model.predict(X_test)
```
```python
# Mean Absolute Error and R2-Score on Unseen Data
from sklearn.metrics import mean_absolute_error, r2_score
print(f'Mean Absolute Error on Unseen Data : {mean_absolute_error(y_test, y_pred_test):.2f}')
print(f'R2-Score on Unseen Data : {r2_score(y_test, y_pred_test):.2f}')
```
```python
# Mean Absolute Percentage Error on Unseen Data
from sklearn.metrics import mean_absolute_percentage_error
mape = mean_absolute_percentage_error(y_test, y_pred_test)
print(f'Mean Absolute Percentage Error on Unseen Data : {mape * 100:.2f}%')
```
Click Here to view Analysis
```
Mean Absolute Error on Unseen Data : 87723.02
R2-Score on Unseen Data : 0.87
Mean Absolute Percentage Error on Unseen Data : 13.93%
```
### 10. Predicting a Price Range
Click Here to view Code Snippet
```python
# Importing GradientBoostingRegressor for Quantile Regression
from sklearn.ensemble import GradientBoostingRegressor
# Lower Bound Pipeline (10th Percentile)
lower_pipe = Pipeline(steps=[
('preprocessor', ctf),
('model', GradientBoostingRegressor(loss='quantile', alpha=0.1, random_state=42))
])
# Upper Bound Pipeline (90th Percentile)
upper_pipe = Pipeline(steps=[
('preprocessor', ctf),
('model', GradientBoostingRegressor(loss='quantile', alpha=0.9, random_state=42))
])
# Fitting Both Quantile Pipelines on Training Data
lower_pipe.fit(X_train, y_train)
upper_pipe.fit(X_train, y_train)
# Predicting Lower and Upper Bounds on Unseen Data
y_pred_lower = lower_pipe.predict(X_test)
y_pred_upper = upper_pipe.predict(X_test)
# Clamping Lower Bound at 0 as a Safety Net (Price can never be Negative)
y_pred_lower = np.clip(y_pred_lower, a_min=0, a_max=None)
```
Click Here to view Analysis
- A single point prediction is not very useful on its own, a **range** is more practical for buyers/sellers.
- The initial approach used a flat `prediction ± MAE` range, but this is flawed :
- MAE is one global average error, it does not scale with the price of the car.
- For cheap cars, `prediction - MAE` could go **negative**, which makes no sense for a price.
- For expensive cars, the same flat range was unrealistically tight.
- It also required the exact training-time MAE in `.env`, which anyone cloning the repo would not have.
- This was replaced with two `GradientBoostingRegressor` models trained directly on the P10 and P90 of price.
- Both are exported as `lower_pipe.pkl` and `upper_pipe.pkl` alongside the main model,
- So the API loads them like any other artifact, no manual `.env` value needed.
- The lower bound is additionally clipped at 0 in the API as a safety net.
## Challenges & Solutions
### Challenge 1 : Getting Real-World Data
#### Problem
- I wanted to use real-world data instead of a toy dataset, as it better represents messy, real-life scenarios.
- However, Cars24 loads its content dynamically using JavaScript, meaning a simple HTTP request is not enough.
#### Solution
- I used [Selenium](https://www.selenium.dev/) to simulate a real browser, ensuring the page was fully loaded before scraping.
- Once the content was rendered, I used [BeautifulSoup](https://www.crummy.com/software/BeautifulSoup/bs4/doc/) to efficiently parse the HTML.
- This approach allowed me to reliably capture complete car details.
### Challenge 2 : Handling Large Datasets Efficiently
#### Problem
- The raw scraped dataset was large and consumed unnecessary memory.
- Loading it repeatedly during experimentation became slow and inefficient.
#### Solution
- I optimized memory usage by downcasting data types.
- I stored the dataset in Parquet format, which compresses data without losing information.
- This enabled much faster read/write performance compared to CSV.
### Challenge 3 : Avoiding Data Leakage
#### Problem
- If preprocessing is applied to the entire dataset, test data can leak into the training process.
- This creates overly optimistic results and reduces the model's ability to generalize.
#### Solution
- I implemented Scikit-learn [Pipeline](https://scikit-learn.org/stable/modules/generated/sklearn.pipeline.Pipeline.html) and [ColumnTransformer](https://scikit-learn.org/stable/modules/generated/sklearn.compose.ColumnTransformer.html) to apply preprocessing only on training data.
- This kept the test data completely unseen during preprocessing, preventing leakage.
### Challenge 4 : Communicating Prediction Uncertainty
#### Problem
- A single point prediction doesn't tell a buyer/seller how confident the model actually is.
- Our initial `prediction ± MAE` range went negative for cheap cars and needed the training-time MAE in `.env`.
#### Solution
- I trained two `GradientBoostingRegressor` models on the 10th and 90th percentile of price (quantile loss).
- The range now scales naturally with the predicted price and can't go negative, with a clip at 0 as a safety net.
- Both models ship as `lower_pipe.pkl`/`upper_pipe.pkl`, so the range updates automatically on retraining.
### Challenge 5 : Deploying the Model as an API
#### Problem
- Even after building the ML pipeline, it remained offline and could only be used locally.
- There was no way to send inputs and get predictions over the web or from other applications.
- The model depended on the local system and could not serve predictions to external users or services.
#### Solution
- I deployed the ML model as an API using [FastAPI](https://fastapi.tiangolo.com/).
- This allowed users and applications to send inputs and receive predictions in real time.
- I added a `/predict` endpoint for predictions and a `/health` endpoint for monitoring API status.
- I implemented input validation and rate limiting to prevent misuse and ensure stability under load.
- These improvements made the API accessible, reliable, and production-ready.
### Challenge 6 : Accessibility for Non-Technical Users
#### Problem
- Even if the API works correctly, non-technical users may still find it difficult to test and use.
- This limits adoption and accessibility.
#### Solution
- I created an HTML/CSS/JS frontend that sends requests to the API and displays predictions instantly.
- I also included an example payload in Swagger UI so users can test the API with minimal effort.
### Challenge 7 : Consistent Deployment Across Environments
#### Problem
- Installing dependencies and setting up the environment manually is time-consuming and error-prone.
- This becomes worse across different machines and operating systems.
- Sharing the project also becomes difficult, since others must replicate the exact setup.
#### Solution
- I created a multi-stage Dockerfile.
- It builds the FastAPI application, installs dependencies, and copies only required files into the final image.
- I used a `.dockerignore` file to exclude unnecessary files and keep the image lightweight.
- This allows the project to run consistently on any system with [Docker](https://www.docker.com/) installed.
- It eliminates dependency mismatches and OS-specific issues.
- Same Docker image can be used to deploy on Render, Docker Hub or run locally with a single docker command.
## Folder Structure
```
AutoIQ/
│
├── api/ # FastAPI Code to deploy API on Render
│ ├── main.py # App instance, middleware, and endpoints
│ ├── models.py # Lifespan loads pipe/model_freq/lower_pipe/upper_pipe
│ ├── schemas.py # Pydantic request & response models
│ └── config.py # Loads and validates environment variables
│
├── clean_data/ # Cleaned Dataset (Parquet Format)
│ └── clean_data.parquet
│ └── ...
│
├── frontend/ # Frontend Application
│ ├── fonts/ # Self-hosted Satoshi font (woff2)
│ ├── images/ # Frontend Assets
│ ├── index.html # Frontend HTML File
│ ├── script.js # Frontend JS File
│ └── style.css # Frontend CSS File
│
├── models/ # Serialized Components for Prediction
│ ├── pipe.pkl # Tuned XGBRegressor pipeline (point estimate)
│ ├── model_freq.pkl # Frequency-encoding dictionary for "model" column
│ ├── lower_pipe.pkl # Quantile pipeline, 10th percentile (price range lower bound)
│ └── upper_pipe.pkl # Quantile pipeline, 90th percentile (price range upper bound)
│
├── notebooks/ # Jupyter Notebooks for Project Development
│ └── ...
│
├── scrape_code/ # Web Scraping Notebook
│ └── scrape_code.ipynb
│
├── scrape_data/ # Scraped Dataset (CSV Format)
│ └── scrape_data.csv
│
├── utils/ # Reusable Python Functions (utils Package)
│ ├── __init__.py
│ ├── web_scraping.py
│ ├── export_data.py
│ └── ...
│
├── .dockerignore # All files and folders ignored by Docker while building Docker Image
├── .env.example # Template for required environment variables
├── .gitignore # All files and folders ignored by Git while pushing code to GitHub
├── Dockerfile # Instructions for building the Docker Image
├── LICENSE # License specifying permissions and usage rights
├── README.md # Detailed documentation of the Project
└── requirements.txt # List of required libraries for the Project
```
## License
This project is licensed under the [MIT License](/AutoIQ/LICENSE). You are free to use and modify the code as needed.
